BMW S54 Engine Guide

The S54B32 is BMW M's 3.2-liter (3,246 cc) naturally aspirated inline-six. BMW's service bulletin on model year 2001 maintenance lists the S54B32 as superseding the S50B32 in the M roadster and M coupe. In US-market cars BMW's parts catalog lists the Z3 M with the S52 until 07/2000 and with the S54 from 02/2001.

The S54 is also the engine of the E46 M3, and the same catalog lists it in the US-market Z4 M Roadster and Coupe through 08/2008.

This guide separates what BMW's own documents prove from what we have not yet established. Where a section says it is not established, that is a research limit, not a verdict.

Quick read

• Ownership position: Not established yet. We are still researching this engine.
• Reliability: No verdict is established here; BMW's bulletins cover rod bearing clearance, a cold-start issue on early Z3 M cars and a software update for the engine lamp, and we found no NHTSA recall for the engine.
• Cost to own: Not established yet.
• Power potential: Not established yet. BMW's S54B32 training module gives the E46 M3 factory output as 333 hp.
• Main watch item: Connecting-rod bearing clearance, covered by a BMW service bulletin rather than a recall.

S54 At a Glance

Question	Practical answer
Sold in US-market BMWs?	Yes, BMW's parts catalog lists the S54 on US-market E46 M3 Coupe and Convertible, Z3 M Coupe and Roadster, and Z4 M Roadster and Coupe types.
Where you find it (US market first)	E46 M3 Coupe built 02/2001-05/2006, E46 M3 Convertible 03/2001-08/2006, Z3 M Coupe and Roadster 02/2001-05/2002, Z4 M Roadster 01/2006-08/2008 and Z4 M Coupe 04/2006-08/2008. The catalog also lists the S54 on non-US types, including the M3 CSL.
Factory output, US market	BMW's S54B32 training module, whose data table labels the torque as US figures, gives 333 hp and 355 Nm in the E46 M3 and 315 hp and 340 Nm in the Z3 M.
Factory output, European E46 M3	BMW's registration data for the European E46 M3 Convertible gives 252 kW at 7,900 rpm and 365 Nm at 4,900 rpm.
Engine oil	The oil change volume with filter is 5.5 liters, and BMW's oil chart lists BMW Motorsport gasoline engine oil, SAE 10W-60, for the S54.
Spark plug	BMW's workshop data names the NGK DCPR8EKP.
Valve clearance	Intake 0.18-0.23 mm and exhaust 0.28-0.33 mm, checked with the engine at or below 35 C.
Maximum engine speed	BMW's workshop data gives 8,000 rpm.
Reliability profile	Not established yet. We are still researching this engine.
Typical annual planning budget	Not established yet.
Before buying	Ask for the maintenance record, including any valve clearance check and any rod or bearing work. BMW added a valve clearance check to Inspection I for the E46 M3.

Technical Specifications

Specification	Detail
Configuration	Inline 6 cylinders, 4 valves per cylinder, naturally aspirated.
Engine code	S54B32; BMW's official designation on the type plate of the European E46 M3 Convertible is 32 6 S 4.
Displacement	3,246 cc.
Bore x stroke	87.0 mm x 91.0 mm.
Compression ratio	11.5:1.
Compression pressure	11-12 bar minimum, about equal on all cylinders.
Block and crank	Cast iron block and forged steel crankshaft.
Valvetrain	Finger followers with adjusting shims; intake valves 35 mm, exhaust valves 30.5 mm, 6.0 mm stems.
VANOS	Double VANOS on both camshafts, operating at 100 bar.
Induction	Six individual throttle housings with an electronic throttle actuator.
Fuel system	Non-return fuel rail with a 5 bar pressure regulator in the fuel filter assembly.
Engine management	MSS 54 on the E46 M3.
Output, US E46 M3	333 hp at 7,900 rpm and 355 Nm at 4,900 rpm.
Output, US Z3 M	315 hp at 7,900 rpm and 340 Nm at 4,900 rpm.
Output, European E46 M3	252 kW at 7,900 rpm and 365 Nm at 4,900 rpm.
Output, Z4 M	Not established yet. We did not find a BMW document that states it.
Engine oil	5.5 liters with filter; BMW Motorsport gasoline engine oil, SAE 10W-60.
Coolant	10.0 liters including the heater on the E46 M3, with an 80 C thermostat.
Emissions, US	BMW's S54B32 training module lists US emission compliance as LEV.
Firing order	Not established yet. We did not find it in a document we opened.

The US horsepower figures and the European kilowatt figures are separate market ratings published in different units, so do not compare them without checking the basis.

Factory Deep Dive

Block and bottom end

BMW's training material says the block is cast iron, with 87 mm bores spaced 91 mm apart, and that the bare block weighs about 48 kg. BMW's training lists a forged steel crankshaft running in 7 main bearings, with 12 counterweights and a 91 mm stroke.

The connecting rods are forged steel and are cracked at the cap, 139 mm long, and BMW's training says a damaged rod bolt cannot be replaced on its own. Graphite-coated cast aluminum pistons get jet cooling from oil nozzles fixed in the crankcase.

Cylinder head and valvetrain

The cylinder head is an aluminum cross-flow design, and a double-roller timing chain drives the camshafts. Cam lift is 12 mm on both camshafts.

The valve fingers act on 9 mm shims, and the exhaust valve stems are sodium filled.

VANOS

Bolted to the front of the cylinder head, the VANOS unit carries four solenoids, a pair per camshaft. The intake camshaft adjusts through 60 degrees and the exhaust camshaft through 45 degrees.

The spread angle ranges are 70-130 degrees for the intake and 83-128 degrees for the exhaust. Oil under pressure for camshaft adjustment is held in a nitrogen-charged accumulator that sits behind the A/C compressor.

Intake, fuel and ignition

A one-piece plastic plenum feeds six individual throttle housings. BMW's training says the non-return fuel system is used for LEV compliance.

The ignition uses six pencil-type coils with the spark plug connector built in.

Oil and cooling

The oil pump is a two-stage design with a supply chamber and a scavenge chamber. BMW's training says a 95 C thermostat in the oil filter housing controls flow to the oil cooler.

The cooling system is a cross-flow design running at 2 bar, with an 80 C thermostat. Blow-by gas leaves through a sealed, unpressurized ventilation circuit, with intake manifold vacuum drawing it through a labyrinth oil separator.

Variants and markets

BMW's training describes the S54B32 as used worldwide, and the training gives separate outputs for the E46 M3 and for the M roadster and M coupe.

Wikipedia lists the US and Canada E46 M3 at 248 kW and 355 Nm.

Service Parts at a Glance

Part numbers below are current as of BMW's parts data dated 12/2019. Check fitment by VIN before ordering.

Part	BMW part number	Note
Oil filter element set	11 42 7 833 769	Listed for the E46 M3, Z3 M and Z4 M with the S54; the same number is listed for the S52 and the US S50.
Spark plug	12 12 0 022 902	NGK DCPR8EKP, quantity 6 per engine.
Ignition coil	12 13 8 616 153	Current number; it replaces 12 13 7 594 937, which BMW discontinued in 02/2015. Quantity 6.
Air filter element	13 72 1 730 449	Listed for the E46 M3 and the Z3 M; it replaces 13 72 1 730 946, discontinued in 11/2013.
Water pump, E46 M3	11 51 7 838 118	Mechanical pump.
Water pump, Z3 M and Z4 M	11 51 7 838 135	Mechanical pump.
Thermostat	11 53 1 318 274	80 C, listed for the E46 M3, Z3 M and Z4 M.
Cylinder head cover	11 12 7 838 754	Listed for the E46 M3, Z3 M and Z4 M.

Known Failure Points and Service Items

Only items backed by a BMW service bulletin or a recall are listed. Whether a specific car is covered is a VIN check with BMW.

01 Connecting-rod bearing clearance

BMW's service bulletin 11 03 01 (739) on the S54B32 says the connecting-rod assembly procedure was changed in production and the minimum bearing clearance for repairs changed from 0.03 mm to 0.04 mm, effective from the start of series production. It also says the rod bolts must not be replaced on this engine, unlike on other BMW engines, and points to repair instruction 11 24 571.

Watch for: the bulletin names no symptom. If an engine has had rod or bearing work, ask whether the repair used the revised minimum clearance. Whether this relates to a failure pattern is not established yet.

02 Cold-start surge on early Z3 M

BMW's service bulletin 11 02 01 (704) covers E36/7 cars with the S54 built from the start of series production to 05/2001 that stall or surge for the first 20-30 seconds after a cold start. BMW gives repeated starts without reaching normal temperature as the cause, because the initial fuel fill can soot the spark plugs.

Watch for: stalling or heavy surging after a cold start that clears when the engine is warm. BMW's remedy is to add at least 25 liters of fuel, bring the engine to normal temperature, and replace the spark plugs if it still misfires or surges heavily when started warm.

03 Engine emergency program lamp

BMW's service bulletin 11 01 03 (998) covers the engine emergency program lamp on the S54 with stored oxygen sensor fault codes, and says the cause is the engine control software data status, not the sensors. BMW says reprogramming the engine control unit is the remedy and that changing the oxygen sensors does not give a lasting fix.

For the E46 the bulletin covers production up to 09/2003, and for the E36/7 it covers production through the end of the series.

Watch for: the emergency program lamp together with oxygen sensor codes.

04 Valve clearance check

BMW's model year 2001 maintenance bulletin 00 16 00 (628) adds a valve clearance check, with adjustment as necessary, to Inspection I on the E46 M3. The clearance is set with shims.

Watch for: no recall applies. We found no BMW document giving a symptom list, so this stays a service item.

Recalls

In NHTSA's recall records for the M3 we found air bag inflator, parking brake, power window and wiring campaigns and none for the engine. This is a limit of our search, not proof that no engine recall exists.

Reliability Verdict

Not established yet. We are still researching this engine. The BMW documents we found are service bulletins for specific build windows, not failure rates.

Power Potential

Not established yet. We are still researching this engine.

Cost of Ownership

Not established yet. We are still researching this engine.

Common Questions

What BMW has the S54 engine?

BMW's parts catalog lists the S54 in the E46 M3, the Z3 M Coupe and Roadster, the Z4 M Roadster and Coupe, and the non-US M3 CSL.

How much oil does an S54 take?

BMW's workshop data gives an oil change volume of 5.5 liters with the filter, and BMW's oil chart lists SAE 10W-60 BMW Motorsport oil.

How much power does the US-market S54 make?

BMW's S54B32 training module gives 333 hp and 355 Nm for the E46 M3 and 315 hp and 340 Nm for the Z3 M, and labels the torque figures as US.

Does the S54 have VANOS?

Yes. BMW's S54B32 training module describes double VANOS, which adjusts both the intake and the exhaust camshafts.

What spark plug does the S54 use?

BMW lists the NGK DCPR8EKP, BMW part number 12 12 0 022 902, with six per engine.

What is the valve clearance on an S54?

BMW's workshop data gives 0.18-0.23 mm for the intake and 0.28-0.33 mm for the exhaust, set with the engine at or below 35 C.

Sources

• BMW training module, M Engines - S54B32 (E46 M3, M roadster, M coupe)
• BMW workshop technical data for the S54 (engine data, oil supply, valves, spark plugs, cooling).
• BMW Service Information 11 03 01 (739), connecting-rod bearing play, S54.
• BMW Service Information 11 02 01 (704), poor warming-up characteristics, E36/7 S54.
• BMW Service Information 11 01 03 (998), engine emergency program lamp, M54/S54/S62.
• BMW Service Information 00 16 00 (628), modification of scope of maintenance jobs, model year 2001.
• BMW SI B11 01 15 (Feb 2017), engine oil chart
• BMW parts catalog data, dated 12/2019, for fitment, build months and part number supersession.
• NHTSA recall records for the BMW M3 (model year 2002 query shown; 2001-2006 were searched)
• Wikipedia, BMW S54 (cross-check only)
